AuCAR USB intelligent Built-in External Sensors Tire Pressure Monitoring System TPMS Match for All Android Car Navigation

Main features:
– Powerful TPMS:
Monitors tire pressure and temperature condition in real time, which will transmit real-time data to the android multimedia system of your car to remind the driver for the comfortableness of vehicle and driving safety.
– Wide application:
This system is widely suitable for vehicle with four tires and the maximum pressure of the tire is below 8 bar, such as a commercial car, jeep, off-road vehicle, minibus, and sedan car, etc.
– Digital display:
Includes a TPMS receiver, four external (and/or internal) sensors. The real-time data of tires will be sent to the android multimedia through USB port, so you can know the status of your car easily and comfortably from the car multimedia system.
– 4 external/internal sensors:
Provides four sensors, which are suitable for using in any type of weather. Besides, they are in high sensitivity and good accuracy for measuring pressure and temperature.



Specifications:
External sensor:
– Battery model: CR1632
– Standby current: < 0.7 uA
– Electric current: < 8 mA
– Working temperature: minus 20 – plus 60 Deg.C
– Temperature measurement range: minus 20 – plus 50 Deg.C
– Pressure measurement range: 0 – 8 Bar
– Transmission frequency: 433.92MHz
Internal sensor:
– Battery model: CR2050W
– Standby current: < 0.7 uA
– Electric current: < 10 mA
– Working temperature: minus 40 – plus 125 Deg.C
– Temperature measurement range: 0 – plus 70 Deg.C
– Pressure measurement range: 0 – 8 Bar
– Transmission frequency: 433.92MHz
TPMS receiver:
– Working voltage: DC 5V
– Working current: less than 16mA
– Working frequency: 433.92MHz
– Working temperature: minus 40 – plus 85 Deg.C
– Interface model: USB
– Please note that our USB TPMS receiver is only suitable for Android car multimedia system
